Especificaciones
Hardware Version
F1
Interfaces (ports)
• 16 x 10/100/1000BASE-T
• 4 x 100/1000Mbps combo
Port Standards
• IEEE 802.3 10BASE-T Ethernet (twisted-pair copper)
• IEEE 802.3u 100BASE-TX Fast Ethernet (twisted-pair copper)
• IEEE 802.3u 100BASE-FX 100 Mbps over fiber optic
• IEEE 802.3ab 1000BASE-T Gigabit Ethernet (twisted- pair copper)
• IEEE 802.3z 1000BASE-X 1 Gbps over fiber optic
• IEEE 802.3az Energy Efficient Ethernet (EEE)
• IEEE 802.3x Flow Control
Network Cables
UTP Cat. 5, Cat. 5e (100 m max.)
Duplex Mode
Full/Half-duplex for 10/100 Mbps
Full-duplex for 1000 Mbps
Media Interface Exchange
Auto MDI/MDIX adjustment for all twisted-pair ports
Switching Capacity
40 Gbps
Transmission Method
Store-and-forward
MAC Address Table
8K entries
Static MAC Addresses
256 entries
Maximum 64 Byte Packet
Forwarding Rate
29.8 Mpps
Packet Buffer Memory
4.1 Mbits
CPU Memory
DDR3 128 MB
Flash Memory
32 MB
Power (per device)
Link/Active/Speed (per port)
Power Input
100 to 240 V AC 50/60 Hz internal universal power supply
Maximum Power Consumption
13.02 W
Standby Power Consumption
5.56 W
Acoustics
0 dB(A)
Heat Dissipation
44.41 BTU/hr
Operating Temperature
-5 to 50°C
Storage Temperature
-20 to 70°C
Operating Humidity
0% to 95% relative humidity
Storage Humidity
0% to 95% relative humidity
Dimensions (L x W x H)
280 x 180 x 44 mm
Weight
1.75 kg
Certifications
EMI: CE Class A, VCCI Class A, FCC Class A, BSMI, CCC
MTBF
1,087,100 hours
